Name: Pavement Ratings New

Display Field: Road_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Pavement Segments serve as the basic units for planning pavement maintenance treatment and reconstruction activity by the Bureau of Highway's Infrastructure Management Division. Each segment is a length of road that has similar pavement condition and other characteristics that makes it suitable for the entire stretch to be paved and/or treated at one time. The segment geometry is derived from -- and is a subset of -- the Street Centerlines feature class. The features and attributes in this layer are sourced from the v_Pavement_CL view in the Road Inventory (dpwroadinv production) database and are copied nightly into the fc_Pavement_CL feature class in the VWDPWGE-Highways database. Changes made to the condition ratings data in the Road Inventory will be reflected in the attributes of this layer following the nightly update.

Service Item Id: 1f8f82b4d4484482a6d76b20ae73a8b7

Copyright Text: Anne Arundel County Department of Public Works, Bureau of Highways

Default Visibility: false

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 500000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1358395.5548781306
YMin: 384237.9407659769
XMax: 1482264.5069428831
YMax: 572041.137665391
Spatial Reference: 2893  (2893)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 24000.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SegID ( type: esriFieldTypeInteger, alias: SegID )
• RoadID ( type: esriFieldTypeInteger, alias: RoadID )
• Road_Name ( type: esriFieldTypeString, alias: Road Name, length: 50 )
• Route_No ( type: esriFieldTypeString, alias: Route No, length: 50 )
• Pave_From ( type: esriFieldTypeString, alias: Pave From, length: 50 )
• Pave_To ( type: esriFieldTypeString, alias: Pave To, length: 50 )
• Length_mi ( type: esriFieldTypeDouble, alias: Length mi )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Length ft )
• Area_lane_mi ( type: esriFieldTypeDouble, alias: Area lane mi )
• Area_sy ( type: esriFieldTypeDouble, alias: Area sy )
• Avg_Width_ft ( type: esriFieldTypeDouble, alias: Avg Width ft )
• Road_Maint_Authority ( type: esriFieldTypeString, alias: Road Maint Authority, length: 35 )
• RMA_Category ( type: esriFieldTypeString, alias: RMA Category, length: 35 )
• Functional_Class_max_value ( type: esriFieldTypeString, alias: Functional Class max value, length: 255 )
• Functional_Class_max_length ( type: esriFieldTypeString, alias: Functional Class max length, length: 255 )
• Status ( type: esriFieldTypeString, alias: Status, length: 15 )
• Snow_Priority_max_value ( type: esriFieldTypeSmallInteger, alias: Snow Priority max value )
• Composition ( type: esriFieldTypeString, alias: Composition, length: 25 )
• Updated_Date ( type: esriFieldTypeDate, alias: Updated Date, length: 8, precision: 1 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Rating_Date ( type: esriFieldTypeDate, alias: Rating Date, length: 8, precision: 1 )
• Rating ( type: esriFieldTypeSmallInteger, alias: Rating )
• CG_Rate ( type: esriFieldTypeString, alias: CG Rate, length: 30 )
• SW_Rate ( type: esriFieldTypeString, alias: SW Rate, length: 30 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
