Name: Pavement Polygons

Display Field: Road_Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Segments serve as the basic units for planning pavement maintenance treatment and reconstruction activity by the Bureau of Highway's Infrastructure Management Division. Each segment is a length of road that has similar pavement condition and other characteristics that makes it suitable for the entire stretch to be paved and/or treated at one time. The segment geometry is derived from -- and is a subset of -- the Street Centerlines feature class. The polygon geometry is derived from the Road Edges. A model is run weekly that assigns each Road Edge a SegID which is then dissolved. The output of that model is then appended to the Pavement Segment Polygons feature class in the Road Inventory after all rows from the Pavement Segment Polygons are dropped. The layer is symbolized by Road Maintenance Authority category.

Copyright Text: Anne Arundel County Dept of Public Works - Bureau of Highways. The attributes and geometry of this feature class are maintained continually by the GIS personnel associated with the Infrastructure Management Division.

Default Visibility: false

MaxRecordCount: 10000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 24000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Unique Id Infos:

Type: simple
Fields: ["SegID"]
OID Field Contains Hash Value: false

Extent:

XMin: 1357976.6236293912
YMin: 384215.06515556574
XMax: 1482282.7355809659
YMax: 572045.7800445557
Spatial Reference: 2893  (2893)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: RMA_Category
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: County BOH
  Label: County BOH
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [168, 112, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 0
• Value: County BOH - Under Warranty
  Label: County BOH - Under Warranty
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 0, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 0
• Value: County BOH - Active PWA
  Label: County BOH - Active PWA
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [85, 255, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [56, 168, 0, 255]
  Width: 0
• Value: County BOH - Maint Agreement
  Label: County BOH - Maint Agreement
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [190, 255, 232, 127]
  Outline:
  Style: esriSLSSolid
  Color: [0, 168, 132, 255]
  Width: 0
• Value: Other County Government
  Label: Other County Government
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [132, 0, 168, 127]
  Outline:
  Style: esriSLSSolid
  Color: [132, 0, 168, 255]
  Width: 0
• Value: <Null>
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Annapolis
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Federal Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Non-Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Other Local Jurisdiction
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: State Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: TBD
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• SegID ( type: esriFieldTypeOID, alias: SegID )
• RoadID ( type: esriFieldTypeInteger, alias: RoadID )
• Road_Name ( type: esriFieldTypeString, alias: Road Name, length: 50 )
• Route_No ( type: esriFieldTypeString, alias: Route No, length: 50 )
• Pave_From ( type: esriFieldTypeString, alias: Pave From, length: 50 )
• Pave_To ( type: esriFieldTypeString, alias: Pave To, length: 50 )
• Length_mi ( type: esriFieldTypeDouble, alias: Length mi )
• Area_lane_mi ( type: esriFieldTypeDouble, alias: Area lane mi )
• Area_sy ( type: esriFieldTypeDouble, alias: Area sy )
• Avg_Width_ft ( type: esriFieldTypeDouble, alias: Avg Width ft )
• Road_Maint_Authority ( type: esriFieldTypeString, alias: Road Maint Authority, length: 35 )
• RMA_Category ( type: esriFieldTypeString, alias: RMA Category, length: 35 )
• Functional_Class_max_value ( type: esriFieldTypeString, alias: Functional Class max value, length: 255 )
• Functional_Class_max_length ( type: esriFieldTypeString, alias: Functional Class max length, length: 255 )
• Status ( type: esriFieldTypeString, alias: Status, length: 15 )
• Snow_Priority_max_value ( type: esriFieldTypeSmallInteger, alias: Snow Priority max value )
• Composition ( type: esriFieldTypeString, alias: Composition, length: 25 )
• Pavement_Inventory_Comments ( type: esriFieldTypeString, alias: Pavement Inventory Comments, length: 500 )
• Created_Date ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• Created_By ( type: esriFieldTypeString, alias: Created By, length: 25 )
• Updated_Date ( type: esriFieldTypeDate, alias: Updated Date, length: 8 )
• Updated_By ( type: esriFieldTypeString, alias: Updated By, length: 25 )
• Archived ( type: esriFieldTypeSmallInteger, alias: Archived )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• GlobalID ( type: esriFieldTypeGUID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GDB_GEOMATTR_DATA ( type: esriFieldTypeBlob, alias: GDB_GEOMATTR_DATA )
• Orig_Construction_Yr ( type: esriFieldTypeInteger, alias: Orig Construction Yr )
• Last_Reconstruction_Yr ( type: esriFieldTypeInteger, alias: Last Reconstruction Yr )
• Last_Hot_Mix_Asphalt_Yr ( type: esriFieldTypeInteger, alias: Last Hot Mix Asphalt Yr )
• Last_Treatment ( type: esriFieldTypeString, alias: Last Treatment, length: 25 )
• Last_Treatment_Category ( type: esriFieldTypeString, alias: Last Treatment Category, length: 25 )
• Last_Treatment_Status ( type: esriFieldTypeString, alias: Last Treatment Status, length: 25 )
• Last_Treatment_Completed_Date ( type: esriFieldTypeDate, alias: Last Treatment Completed Date, length: 8 )
• Last_Treatment_Comments ( type: esriFieldTypeString, alias: Last Treatment Comments, length: 2000 )
• Last_PO_No ( type: esriFieldTypeString, alias: Last PO No, length: 25 )
• Last_Contract_No ( type: esriFieldTypeString, alias: Last Contract No, length: 15 )
• Last_Contract_Desc ( type: esriFieldTypeString, alias: Last Contract Desc, length: 75 )
• Last_Contractor ( type: esriFieldTypeString, alias: Last Contractor, length: 50 )
• Last_FY_Fund ( type: esriFieldTypeSmallInteger, alias: Last FY Fund )
• Last_Account_No ( type: esriFieldTypeString, alias: Last Account No, length: 12 )
• Last_Program ( type: esriFieldTypeString, alias: Last Program, length: 25 )
• Last_Program_Category ( type: esriFieldTypeString, alias: Last Program Category, length: 25 )
• Next_Treatment ( type: esriFieldTypeString, alias: Next_Treatment, length: 25 )
• Next_Treatment_Category ( type: esriFieldTypeString, alias: Next_Treatment_Category, length: 25 )
• Next_FY_Planned ( type: esriFieldTypeSmallInteger, alias: Next_FY_Planned )
• Next_Treatment_Status ( type: esriFieldTypeString, alias: Next_Treatment_Status, length: 25 )
• Rate_Cycle ( type: esriFieldTypeString, alias: Rate Cycle, length: 1 )
• Rating_Date ( type: esriFieldTypeDate, alias: Rating Date, length: 8 )
• Rated_By ( type: esriFieldTypeString, alias: Rated By, length: 25 )
• Rating_Method ( type: esriFieldTypeString, alias: Rating_Method, length: 1 )
• Rating ( type: esriFieldTypeSmallInteger, alias: Rating )
• Rating_Calc ( type: esriFieldTypeSmallInteger, alias: Rating Calc )
• Rating_Override ( type: esriFieldTypeSmallInteger, alias: Rating Override )
• Rating_Override_Reason ( type: esriFieldTypeString, alias: Rating Override Reason, length: 500 )
• Pavement_Condition_Comments ( type: esriFieldTypeString, alias: Pavement Condition Comments, length: 2000 )
• Trans_Rate ( type: esriFieldTypeSmallInteger, alias: Trans Rate )
• Long_Rate ( type: esriFieldTypeSmallInteger, alias: Long Rate )
• Allig_Rate ( type: esriFieldTypeSmallInteger, alias: Allig Rate )
• Shrink_Rate ( type: esriFieldTypeSmallInteger, alias: Shrink Rate )
• Rut_Rate ( type: esriFieldTypeSmallInteger, alias: Rut Rate )
• Corrug_Rate ( type: esriFieldTypeSmallInteger, alias: Corrug Rate )
• Ravel_Rate ( type: esriFieldTypeSmallInteger, alias: Ravel Rate )
• Push_Rate ( type: esriFieldTypeSmallInteger, alias: Push Rate )
• Holes_Rate ( type: esriFieldTypeSmallInteger, alias: Holes Rate )
• Bleed_Rate ( type: esriFieldTypeSmallInteger, alias: Bleed Rate )
• Pol_Ag_Rate ( type: esriFieldTypeSmallInteger, alias: Pol Ag Rate )
• Drain_Rate ( type: esriFieldTypeSmallInteger, alias: Drain Rate )
• Ride_Rate ( type: esriFieldTypeSmallInteger, alias: Ride Rate )
• Traffic_Rate ( type: esriFieldTypeSmallInteger, alias: Traffic_Rate )
• CG_Rate ( type: esriFieldTypeString, alias: CG_Rate, length: 30 )
• SW_Rate ( type: esriFieldTypeString, alias: SW_Rate, length: 30 )
• Curb_Concrete_Length_mi ( type: esriFieldTypeDouble, alias: Curb_Concrete_Length_mi )
• Curb_Asphalt_Length_mi ( type: esriFieldTypeDouble, alias: Curb_Asphalt_Length_mi )
• Sidewalk_Concrete_Length_mi ( type: esriFieldTypeDouble, alias: Sidewalk_Concrete_Length_mi )
• Sidewalk_Asphalt_Length_mi ( type: esriFieldTypeDouble, alias: Sidewalk_Asphalt_Length_mi )
• Road_District ( type: esriFieldTypeString, alias: Road_District, length: 50 )
• Road_Yard ( type: esriFieldTypeString, alias: Road_Yard, length: 50 )
• Road_Supervisor_Area ( type: esriFieldTypeString, alias: Road_Supervisor_Area, length: 50 )
• Snow_Contract_Zone ( type: esriFieldTypeString, alias: Snow_Contract_Zone, length: 50 )
• Weeded_Lot_Inspection_Zone ( type: esriFieldTypeString, alias: Weeded_Lot_Inspection_Zone, length: 50 )
• Regional_Planning_Area ( type: esriFieldTypeString, alias: Regional_Planning_Area, length: 50 )
• Council_District ( type: esriFieldTypeString, alias: Council_District, length: 50 )
• Legislative_District ( type: esriFieldTypeString, alias: Legislative_District, length: 50 )
• Police_District ( type: esriFieldTypeString, alias: Police_District, length: 50 )
• City ( type: esriFieldTypeString, alias: City, length: 50 )
• Subdivision ( type: esriFieldTypeString, alias: Subdivision, length: 50 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
