Name: Pavement Polygons

Display Field: Road_Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Pavement segments serve as the basic units for planning pavement maintenance treatment and reconstruction activity by the Bureau of Highway's Infrastructure Management Division. Each segment is a length of road maintained by the BOH that has similar pavement condition and other characteristics that makes it suitable for the entire stretch to be paved and/or treated at one time. This Pavement Polygons layer is the middle level of the Road Hierarchy maintained within the Road Inventory database. Each pavement segment is composed of one or more street segments. The polygon geometry in this layer is derived from both the Pavement Centerlines and Road Edges feature classes. A model is run monthly that assigns each Road Edge polygon a SegID from the overlaid Pavement Centerlines feature class, which is then used to dissolve Road Edge polygons into Pavement Polygons. The output of that model is then appended to the Pavement Segment Polygons feature class in the Road Inventory database. The pavement segment attributes, condition ratings, and treatment histories are sourced directly from the Road Inventory Database. Road Maintenance Authority Category is symbolized by color. This layer includes only active records with geometry, i.e., it does NOT contain any archived records.This layer is sourced from the VWDPWGE.Highways.fc_Pavement_Poly feature class, which is refreshed nightly from data in the VWDPWGE.Highways v_Pavement_Poly_FC view that in turn queries the DPWROADINV.RoadInventory.v_Pavement_Poly view. This layer should render more quickly than others sourced directly from the DPWROADINV.RoadInventory.v_Pavement_Poly view, but will not immediately reflect data updates made in the Road Inventory database.

Copyright Text: Anne Arundel County Department of Public Works, Bureau of Highways. The attributes and geometry of this feature class are maintained continually by the DPW Bureau of Highways' Infrastructure Management Division and BOH GIS staff.

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1357976.6236293912
YMin: 384215.06515556574
XMax: 1482282.7355809659
YMax: 572045.7800445557
Spatial Reference: 2893  (2893)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: RMA_Category
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: County BOH
  Label: County BOH
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [168, 112, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 0
• Value: County BOH - Under Warranty
  Label: County BOH - Under Warranty
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 0, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 0
• Value: County BOH - Active PWA
  Label: County BOH - Active PWA
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [85, 255, 0, 127]
  Outline:
  Style: esriSLSSolid
  Color: [56, 168, 0, 255]
  Width: 0
• Value: County BOH - Maint Agreement
  Label: County BOH - Maint Agreement
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [190, 255, 232, 127]
  Outline:
  Style: esriSLSSolid
  Color: [0, 168, 132, 255]
  Width: 0
• Value: Other County Government
  Label: Other County Government
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [132, 0, 168, 127]
  Outline:
  Style: esriSLSSolid
  Color: [132, 0, 168, 255]
  Width: 0
• Value: <Null>
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Annapolis
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Federal Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Non-Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: Other Local Jurisdiction
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: State Government
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: TBD
  Label: Not Assigned
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [204, 204, 204, 128]
  Outline:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [168, 112, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• SegID ( type: esriFieldTypeInteger, alias: SegID )
• RoadID ( type: esriFieldTypeInteger, alias: RoadID )
• Road_Name ( type: esriFieldTypeString, alias: Road Name, length: 50 )
• Route_No ( type: esriFieldTypeString, alias: Route No, length: 50 )
• Pave_From ( type: esriFieldTypeString, alias: Pave From, length: 50 )
• Pave_To ( type: esriFieldTypeString, alias: Pave To, length: 50 )
• Length_mi ( type: esriFieldTypeDouble, alias: Length mi )
• Area_lane_mi ( type: esriFieldTypeDouble, alias: Area lane mi )
• Area_sy ( type: esriFieldTypeDouble, alias: Area sy )
• Avg_Width_ft ( type: esriFieldTypeDouble, alias: Avg Width ft )
• Road_Maint_Authority ( type: esriFieldTypeString, alias: Road Maint Authority, length: 35 )
• RMA_Category ( type: esriFieldTypeString, alias: RMA Category, length: 35 )
• Functional_Class_max_value ( type: esriFieldTypeString, alias: Functional Class max value, length: 255 )
• Functional_Class_max_length ( type: esriFieldTypeString, alias: Functional Class max length, length: 255 )
• Status ( type: esriFieldTypeString, alias: Status, length: 15 )
• Snow_Priority_max_value ( type: esriFieldTypeSmallInteger, alias: Snow Priority max value )
• Composition ( type: esriFieldTypeString, alias: Composition, length: 25 )
• Road_District ( type: esriFieldTypeString, alias: Road_District, length: 50 )
• Road_Yard ( type: esriFieldTypeString, alias: Road_Yard, length: 50 )
• Road_Supervisor_Area ( type: esriFieldTypeString, alias: Road_Supervisor_Area, length: 50 )
• Snow_Contract_Zone ( type: esriFieldTypeString, alias: Snow_Contract_Zone, length: 50 )
• Regional_Planning_Area ( type: esriFieldTypeString, alias: Regional_Planning_Area, length: 50 )
• Weeded_Lot_Inspection_Zone ( type: esriFieldTypeString, alias: Weeded_Lot_Inspection_Zone, length: 50 )
• Council_District ( type: esriFieldTypeString, alias: Council_District, length: 50 )
• Legislative_District ( type: esriFieldTypeString, alias: Legislative_District, length: 50 )
• Police_District ( type: esriFieldTypeString, alias: Police_District, length: 50 )
• City ( type: esriFieldTypeString, alias: City, length: 50 )
• Subdivision ( type: esriFieldTypeString, alias: Subdivision, length: 50 )
• Created_Date ( type: esriFieldTypeDate, alias: Created Date, length: 8, precision: 1 )
• Created_By ( type: esriFieldTypeString, alias: Created By, length: 25 )
• Updated_Date ( type: esriFieldTypeDate, alias: Updated Date, length: 8, precision: 1 )
• Updated_By ( type: esriFieldTypeString, alias: Updated By, length: 25 )
• Archived ( type: esriFieldTypeSmallInteger, alias: Archived )
• Pavement_Inventory_Comments ( type: esriFieldTypeString, alias: Pavement Inventory Comments, length: 500 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Orig_Construction_Yr ( type: esriFieldTypeInteger, alias: Orig Construction Yr )
• Last_Reconstruction_Yr ( type: esriFieldTypeInteger, alias: Last Reconstruction Yr )
• Last_Hot_Mix_Asphalt_Yr ( type: esriFieldTypeInteger, alias: Last Hot Mix Asphalt Yr )
• Last_Treatment ( type: esriFieldTypeString, alias: Last Treatment, length: 25 )
• Last_Treatment_Category ( type: esriFieldTypeString, alias: Last Treatment Category, length: 25 )
• Last_Treatment_Status ( type: esriFieldTypeString, alias: Last Treatment Status, length: 25 )
• Last_Treatment_Completed_Date ( type: esriFieldTypeDate, alias: Last Treatment Completed Date, length: 8, precision: 1 )
• Last_Treatment_Comments ( type: esriFieldTypeString, alias: Last Treatment Comments, length: 2000 )
• Last_PO_No ( type: esriFieldTypeString, alias: Last PO No, length: 25 )
• Last_Contract_No ( type: esriFieldTypeString, alias: Last Contract No, length: 15 )
• Last_Contract_Desc ( type: esriFieldTypeString, alias: Last Contract Desc, length: 75 )
• Last_Contractor ( type: esriFieldTypeString, alias: Last Contractor, length: 50 )
• Last_FY_Fund ( type: esriFieldTypeSmallInteger, alias: Last FY Fund )
• Last_Account_No ( type: esriFieldTypeString, alias: Last Account No, length: 12 )
• Last_Program ( type: esriFieldTypeString, alias: Last Program, length: 25 )
• Last_Program_Category ( type: esriFieldTypeString, alias: Last Program Category, length: 25 )
• Next_Treatment ( type: esriFieldTypeString, alias: Next_Treatment, length: 25 )
• Next_Treatment_Category ( type: esriFieldTypeString, alias: Next_Treatment_Category, length: 25 )
• Next_FY_Planned ( type: esriFieldTypeSmallInteger, alias: Next_FY_Planned )
• Next_Treatment_Status ( type: esriFieldTypeString, alias: Next_Treatment_Status, length: 25 )
• Rate_Cycle ( type: esriFieldTypeString, alias: Rate Cycle, length: 1 )
• Rating_Date ( type: esriFieldTypeDate, alias: Rating Date, length: 8, precision: 1 )
• Rated_By ( type: esriFieldTypeString, alias: Rated By, length: 25 )
• Rating_Method ( type: esriFieldTypeString, alias: Rating_Method, length: 1 )
• Rating ( type: esriFieldTypeSmallInteger, alias: Rating )
• Rating_Calc ( type: esriFieldTypeSmallInteger, alias: Rating Calc )
• Rating_Override ( type: esriFieldTypeSmallInteger, alias: Rating Override )
• Rating_Override_Reason ( type: esriFieldTypeString, alias: Rating Override Reason, length: 500 )
• Pavement_Condition_Comments ( type: esriFieldTypeString, alias: Pavement Condition Comments, length: 2000 )
• Trans_Rate ( type: esriFieldTypeSmallInteger, alias: Trans Rate )
• Long_Rate ( type: esriFieldTypeSmallInteger, alias: Long Rate )
• Allig_Rate ( type: esriFieldTypeSmallInteger, alias: Allig Rate )
• Shrink_Rate ( type: esriFieldTypeSmallInteger, alias: Shrink Rate )
• Rut_Rate ( type: esriFieldTypeSmallInteger, alias: Rut Rate )
• Corrug_Rate ( type: esriFieldTypeSmallInteger, alias: Corrug Rate )
• Ravel_Rate ( type: esriFieldTypeSmallInteger, alias: Ravel Rate )
• Push_Rate ( type: esriFieldTypeSmallInteger, alias: Push Rate )
• Holes_Rate ( type: esriFieldTypeSmallInteger, alias: Holes Rate )
• Bleed_Rate ( type: esriFieldTypeSmallInteger, alias: Bleed Rate )
• Pol_Ag_Rate ( type: esriFieldTypeSmallInteger, alias: Pol Ag Rate )
• Drain_Rate ( type: esriFieldTypeSmallInteger, alias: Drain Rate )
• Ride_Rate ( type: esriFieldTypeSmallInteger, alias: Ride Rate )
• Traffic_Rate ( type: esriFieldTypeSmallInteger, alias: Traffic_Rate )
• CG_Rate ( type: esriFieldTypeString, alias: CG_Rate, length: 30 )
• SW_Rate ( type: esriFieldTypeString, alias: SW_Rate, length: 30 )
• Curb_Concrete_Length_mi ( type: esriFieldTypeDouble, alias: Curb_Concrete_Length_mi )
• Curb_Asphalt_Length_mi ( type: esriFieldTypeDouble, alias: Curb_Asphalt_Length_mi )
• Sidewalk_Concrete_Length_mi ( type: esriFieldTypeDouble, alias: Sidewalk_Concrete_Length_mi )
• Sidewalk_Asphalt_Length_mi ( type: esriFieldTypeDouble, alias: Sidewalk_Asphalt_Length_mi )
• Source_OID ( type: esriFieldTypeInteger, alias: Source_OID )
• Source_GUID ( type: esriFieldTypeGUID, alias: Source_GUID, length: 38 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
