Name: Streets

Display Field: NAMEFULL

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><DIV STYLE="font-size:12pt"><P><SPAN>This feature class shows the all of the Streets (Street Centerlines) that will be used for the ROW Permitting App. Before the creation of this feature class, the Accela ROW Permitting App used the Road Class from the BOH Road Inventory. The Road Class attribute is being retired and the FCC designation from the Street Centerlines feature class (maintained by OIT-GIS, FCC attribute designated by OPZ and Transportation). The feature class was made by using the StreetCenterlineSegIDMatchTool created by Sarah Huber (KCI) to assign a Pavement Segment SegID to each Street Centerline feature. The result of that tool created the Street_Centerlines_SegID feature class (Roads dataset, VWDPWGE server) which was then joined with the Pavement Segments feature class and the RoadCond_RoadInv_Join_To_Segs view (VWDPWGE server) to create a view called Street_Centerlines_RCRI_Abridged. That view was then exported as a feature class of the same name (Roads dataset, VWDPWGE server). The feature class was added to the map and symbolized on Road Maintenance Authority.</SPAN></P></DIV></DIV></DIV></DIV>

Copyright Text: Anne Arundel County Dept of Public Works, Bureau of Highways, GIS. Created May 2023.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1358018.9194765538
YMin: 381544.88742506504
XMax: 1491416.6408695579
YMax: 572146.1404081434
Spatial Reference: 2893  (2893)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OWNERSTRING
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: County (0)
  Label: County
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 2
• Value: Private (1)
  Label: Private
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 0, 255]
  Width: 2
• Value: Annapolis (2)
  Label: City of Annapolis
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 190, 232, 255]
  Width: 2
• Value: SHA (3)
  Label: SHA
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 178, 255, 255]
  Width: 2
• Value: Ft. Meade (4)
  Label: Ft. Meade
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [190, 255, 232, 255]
  Width: 2
• Value: Active PWA (5)
  Label: Active PWA
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [85, 255, 0, 255]
  Width: 2
• Value: Under Warranty (7)
  Label: Under Warranty
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 0, 0, 255]
  Width: 2
• Value: Naval Academy (8)
  Label: Naval Academy
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
• Value: BWI Airport (9)
  Label: BWI Airport
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 2
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 10000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• AAID ( type: esriFieldTypeInteger, alias: AAID )
• NAMEFULL ( type: esriFieldTypeString, alias: Name, length: 40 )
• FROMLEFT ( type: esriFieldTypeInteger, alias: From Left )
• TOLEFT ( type: esriFieldTypeInteger, alias: To Left )
• FROMRIGHT ( type: esriFieldTypeInteger, alias: From Right )
• TORIGHT ( type: esriFieldTypeInteger, alias: To Right )
• L_ZIP ( type: esriFieldTypeInteger, alias: L Zip )
• R_ZIP ( type: esriFieldTypeInteger, alias: R Zip )
• FCC ( type: esriFieldTypeString, alias: FCC, length: 25 )
• BMC_ID ( type: esriFieldTypeInteger, alias: BMC ID )
• AAROADNO ( type: esriFieldTypeSmallInteger, alias: AA Road No )
• STATENUM ( type: esriFieldTypeString, alias: State Num, length: 30 )
• SUBDIVISION ( type: esriFieldTypeString, alias: Subdivision, length: 35 )
• CITY ( type: esriFieldTypeString, alias: City, length: 20 )
• ROADDISTYARD ( type: esriFieldTypeString, alias: Road Dist Yard, length: 25 )
• OWNERSHIP ( type: esriFieldTypeSmallInteger, alias: Ownership )
• OWNERSTRING ( type: esriFieldTypeString, alias: Ownerstring, length: 20 )
• PAVEFROM ( type: esriFieldTypeString, alias: Pave From, length: 50 )
• PAVETO ( type: esriFieldTypeString, alias: Pave To, length: 50 )
• RATINGDATE ( type: esriFieldTypeDate, alias: Rating Date, length: 8 )
• NUMRATING ( type: esriFieldTypeSmallInteger, alias: Num Rating )
• REHABDATE ( type: esriFieldTypeDate, alias: Rehab Date, length: 8 )
• REHABTYPE ( type: esriFieldTypeString, alias: Rehab Type, length: 20 )
• CONTRACT ( type: esriFieldTypeString, alias: Contract, length: 10 )
• PROGRAM ( type: esriFieldTypeString, alias: Program, length: 5 )
• FYFUNDS ( type: esriFieldTypeString, alias: FY Funds, length: 9 )
• REHABSTATUS ( type: esriFieldTypeString, alias: Rehab Status, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• SEG_ID ( type: esriFieldTypeInteger, alias: Seg_ID )
• RoadClass ( type: esriFieldTypeString, alias: Road Class, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
