Name: Road Centerlines

Display Field: Road_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The line geometry of this feature class is derived from the Street Centerline dissolved on AARoadNo (RoadID), and is refreshed from its source nightly. Road attributes are sourced via a "live" connection to the Road Inventory Database. Updates made to the Road Inventory database are immediately reflected in the attributes of this layer. The layer is symbolized by road maintenance authority and the Street Centerlines functional class (FCC) where arterials are displayed as thick lines, collectors are displayed as medium thickness, and locals are displayed as thin lines ; Roads with a 'Planned' status are symbolized as dashed lines. These features do NOT contain any archived records and consist of only active records with geometry.

Service Item Id: 9d406579295b44f4b11e2106f3405d4c

Copyright Text: Anne Arundel County Dept of Public Works - Bureau of Highways. The attributes and geometry of this feature class are maintained continually by the GIS personnel associated with the Infrastructure Management Division.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 24000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1358018.9194765538
YMin: 381544.88742506504
XMax: 1491416.6408695579
YMax: 572146.1404081434
Spatial Reference: 2893  (2893)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: RMA_Category
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: County BOH
  Label: County BOH
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 4
• Value: County BOH - Under Warranty
  Label: County BOH - Under Warranty
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 4
• Value: County BOH - Active PWA
  Label: County BOH - Active PWA
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [85, 255, 0, 255]
  Width: 4
• Value: County BOH - Maint Agreement
  Label: County BOH - Maint Agreement
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 168, 132, 255]
  Width: 4
• Value: Other County Government
  Label: Other County Government
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [132, 0, 168, 255]
  Width: 4
• Value: State Government
  Label: State Government
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 178, 255, 255]
  Width: 4
• Value: Federal Government
  Label: Federal Government
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 92, 230, 255]
  Width: 4
• Value: Annapolis
  Label: Annapolis
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 190, 232, 255]
  Width: 4
• Value: Other Local Jurisdiction
  Label: Other Local Jurisdiction
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [104, 104, 104, 255]
  Width: 4
• Value: Non-Government
  Label: Non-Government
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 0, 255]
  Width: 4
• Value: TBD
  Label: TBD
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 4
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 10000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ESRI_OID ( type: esriFieldTypeOID, alias: ESRI_OID, length: 8 )
• RoadID ( type: esriFieldTypeInteger, alias: RoadID )
• State_Road_No ( type: esriFieldTypeString, alias: State_Road_No, length: 30 )
• Road_Name ( type: esriFieldTypeString, alias: Road_Name, length: 50 )
• Route_No ( type: esriFieldTypeString, alias: Route_No, length: 50 )
• Road_From ( type: esriFieldTypeString, alias: Road_From, length: 50 )
• Road_To ( type: esriFieldTypeString, alias: Road_To, length: 50 )
• Length_mi ( type: esriFieldTypeDouble, alias: Length_mi )
• ROW_Width_ft ( type: esriFieldTypeSmallInteger, alias: ROW_Width_ft )
• ROW_Varies ( type: esriFieldTypeSmallInteger, alias: ROW_Varies )
• Road_Maint_Authority ( type: esriFieldTypeString, alias: Road_Maint_Authority, length: 35 )
• RMA_Category ( type: esriFieldTypeString, alias: RMA_Category, length: 35 )
• Functional_Class_max_value ( type: esriFieldTypeString, alias: Functional_Class_max_value, length: 25 )
• Functional_Class_max_length ( type: esriFieldTypeString, alias: Functional_Class_max_length, length: 25 )
• Status ( type: esriFieldTypeString, alias: Status, length: 20 )
• Acceptance_Date ( type: esriFieldTypeDateOnly, alias: Acceptance_Date )
• Road_Inventory_Comments ( type: esriFieldTypeString, alias: Road_Inventory_Comments, length: 2000 )
• Archived ( type: esriFieldTypeSmallInteger, alias: Archived )
• Created_Date ( type: esriFieldTypeDate, alias: Created_Date, length: 8, precision: 1 )
• Created_By ( type: esriFieldTypeString, alias: Created_By, length: 25 )
• Updated_Date ( type: esriFieldTypeDate, alias: Updated_Date, length: 8, precision: 1 )
• Updated_By ( type: esriFieldTypeString, alias: Updated_By, length: 25 )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• GlobalID ( type: esriFieldTypeGUID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GDB_GEOMATTR_DATA ( type: esriFieldTypeBlob, alias: GDB_GEOMATTR_DATA )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
