Name: Longlines

Display Field: Road_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The following read-only service is a view that combines longline attribute data with another view from the road inventory that details county pavement information. These views are joined together based on matching SEGMENT IDs and utilize the geometry from the pavement view. If no matching SEGMENT ID is found between a longline feature and the pavement view, related pavement fields will not be populated or display geometry. The main purpose of the service is to allow traffic users that edit a separate longline attribute table the ability to easily reference current/existing pavement information to populate longline data fields with relevant values.

Service Item Id: 9d406579295b44f4b11e2106f3405d4c

Copyright Text: Anne Arundel County Bureau of Highways Traffic Division

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 500000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.2056072506320147E8
YMin: -9.544398243155015E7
XMax: 1.2318539172986814E8
YMax: 7.399815174566643E7
Spatial Reference: 2893  (2893)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Candidate_Road
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 0
  Label: Non-Programmed
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [232, 190, 255, 255]
  Width: 2
• Value: 1
  Label: Programmed
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [169, 0, 230, 255]
  Width: 2
• Value: 2
  Label: Programmed - Marked
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 92, 230, 255]
  Width: 2
• Value: 3
  Label: Non-Programmed - Marked
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 178, 255, 255]
  Width: 2
• Value: 5
  Label: Programmed - Not Marked
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [0, 38, 115, 255]
  Width: 2
• Value: 4
  Label: Do Not Paint
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [255, 0, 0, 255]
  Width: 2
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OID ( type: esriFieldTypeBigInteger, alias: OID )
• Asset_ID ( type: esriFieldTypeString, alias: Asset_ID, length: 50 )
• SEG_ID ( type: esriFieldTypeInteger, alias: SEG_ID )
• Double_Yellow ( type: esriFieldTypeDouble, alias: Double_Yellow )
• Edgeline_SW ( type: esriFieldTypeDouble, alias: Edgeline_SW )
• Marking_Type ( type: esriFieldTypeString, alias: Marking_Type, length: 100 )
• Marking_Required ( type: esriFieldTypeString, alias: Marking_Required, length: 3 )
• IMD_FY_Improvement ( type: esriFieldTypeInteger, alias: IMD_FY_Improvement )
• IMD_Resurfacing ( type: esriFieldTypeString, alias: IMD_Resurfacing, length: 3 )
• Candidate_Road ( type: esriFieldTypeSmallInteger, alias: Candidate_Road )
• Candidate_Eval_Date ( type: esriFieldTypeDate, alias: Candidate_Eval_Date, length: 8, precision: 1 )
• PavSeg_SegID ( type: esriFieldTypeInteger, alias: PavSeg_SegID )
• PavSeg_RoadID ( type: esriFieldTypeInteger, alias: PavSeg_RoadID )
• PavSeg_Road_Name ( type: esriFieldTypeString, alias: PavSeg_Road_Name, length: 50 )
• Route_No ( type: esriFieldTypeString, alias: Route_No, length: 50 )
• Pave_From ( type: esriFieldTypeString, alias: Pave_From, length: 50 )
• Pave_To ( type: esriFieldTypeString, alias: Pave_To, length: 50 )
• Length_mi ( type: esriFieldTypeDouble, alias: Length_mi )
• Area_lane_mi ( type: esriFieldTypeDouble, alias: Area_lane_mi )
• Area_sy ( type: esriFieldTypeDouble, alias: Area_sy )
• Avg_Width_ft ( type: esriFieldTypeDouble, alias: Avg_Width_ft )
• Road_Maint_Authority ( type: esriFieldTypeString, alias: Road_Maint_Authority, length: 35 )
• RMA_Category ( type: esriFieldTypeString, alias: RMA_Category, length: 35 )
• Functional_Class_max_value ( type: esriFieldTypeString, alias: Functional_Class_max_value, length: 255 )
• Functional_Class_max_length ( type: esriFieldTypeString, alias: Functional_Class_max_length, length: 255 )
• PavSeg_Status ( type: esriFieldTypeString, alias: PavSeg_Status, length: 15 )
• Snow_Priority_max_value ( type: esriFieldTypeSmallInteger, alias: Snow_Priority_max_value )
• Composition ( type: esriFieldTypeString, alias: Composition, length: 25 )
• Pavement_Inventory_Comments ( type: esriFieldTypeString, alias: Pavement_Inventory_Comments, length: 500 )
• PavSeg_Created_Date ( type: esriFieldTypeDate, alias: PavSeg_Created_Date, length: 8, precision: 1 )
• PavSeg_Created_By ( type: esriFieldTypeString, alias: PavSeg_Created_By, length: 25 )
• PavSeg_Updated_Date ( type: esriFieldTypeDate, alias: PavSeg_Updated_Date, length: 8, precision: 1 )
• PavSeg_Updated_By ( type: esriFieldTypeString, alias: PavSeg_Updated_By, length: 25 )
• Archived ( type: esriFieldTypeSmallInteger, alias: Archived )
• PavSeg_OBJECTID ( type: esriFieldTypeInteger, alias: PavSeg_OBJECTID )
• PavSeg_GlobalID ( type: esriFieldTypeGUID, alias: PavSeg_GlobalID, length: 38 )
• PavSeg_Shape ( type: esriFieldTypeGeometry, alias: PavSeg_Shape )
• Orig_Construction_Yr ( type: esriFieldTypeInteger, alias: Orig_Construction_Yr )
• Last_Reconstruction_Yr ( type: esriFieldTypeInteger, alias: Last_Reconstruction_Yr )
• Last_Hot_Mix_Asphalt_Yr ( type: esriFieldTypeInteger, alias: Last_Hot_Mix_Asphalt_Yr )
• Last_Treatment ( type: esriFieldTypeString, alias: Last_Treatment, length: 25 )
• Last_Treatment_Category ( type: esriFieldTypeString, alias: Last_Treatment_Category, length: 25 )
• Last_Treatment_Status ( type: esriFieldTypeString, alias: Last_Treatment_Status, length: 25 )
• Last_Treatment_Completed_Date ( type: esriFieldTypeDateOnly, alias: Last_Treatment_Completed_Date )
• Last_Treatment_Comments ( type: esriFieldTypeString, alias: Last_Treatment_Comments, length: 2000 )
• Last_PO_No ( type: esriFieldTypeString, alias: Last_PO_No, length: 25 )
• Last_Contract_No ( type: esriFieldTypeString, alias: Last_Contract_No, length: 15 )
• Last_Contract_Desc ( type: esriFieldTypeString, alias: Last_Contract_Desc, length: 75 )
• Last_Contractor ( type: esriFieldTypeString, alias: Last_Contractor, length: 50 )
• Last_FY_Fund ( type: esriFieldTypeSmallInteger, alias: Last_FY_Fund )
• Last_Account_No ( type: esriFieldTypeString, alias: Last_Account_No, length: 12 )
• Last_Program ( type: esriFieldTypeString, alias: Last_Program, length: 25 )
• Last_Program_Category ( type: esriFieldTypeString, alias: Last_Program_Category, length: 25 )
• Next_Treatment ( type: esriFieldTypeString, alias: Next_Treatment, length: 25 )
• Next_Treatment_Category ( type: esriFieldTypeString, alias: Next_Treatment_Category, length: 25 )
• Next_FY_Planned ( type: esriFieldTypeSmallInteger, alias: Next_FY_Planned )
• Next_Treatment_Status ( type: esriFieldTypeString, alias: Next_Treatment_Status, length: 25 )
• Rate_Cycle ( type: esriFieldTypeString, alias: Rate_Cycle, length: 1 )
• Rating_Date ( type: esriFieldTypeDateOnly, alias: Rating_Date )
• Rated_By ( type: esriFieldTypeString, alias: Rated_By, length: 25 )
• Rating_Method ( type: esriFieldTypeString, alias: Rating_Method, length: 1 )
• Rating ( type: esriFieldTypeSmallInteger, alias: Rating )
• Rating_Calc ( type: esriFieldTypeSmallInteger, alias: Rating_Calc )
• Rating_Override ( type: esriFieldTypeSmallInteger, alias: Rating_Override )
• Rating_Override_Reason ( type: esriFieldTypeString, alias: Rating_Override_Reason, length: 500 )
• Pavement_Condition_Comments ( type: esriFieldTypeString, alias: Pavement_Condition_Comments, length: 2000 )
• Trans_Rate ( type: esriFieldTypeSmallInteger, alias: Trans_Rate )
• Long_Rate ( type: esriFieldTypeSmallInteger, alias: Long_Rate )
• Allig_Rate ( type: esriFieldTypeSmallInteger, alias: Allig_Rate )
• Shrink_Rate ( type: esriFieldTypeSmallInteger, alias: Shrink_Rate )
• Rut_Rate ( type: esriFieldTypeSmallInteger, alias: Rut_Rate )
• Corrug_Rate ( type: esriFieldTypeSmallInteger, alias: Corrug_Rate )
• Ravel_Rate ( type: esriFieldTypeSmallInteger, alias: Ravel_Rate )
• Push_Rate ( type: esriFieldTypeSmallInteger, alias: Push_Rate )
• Holes_Rate ( type: esriFieldTypeSmallInteger, alias: Holes_Rate )
• Bleed_Rate ( type: esriFieldTypeSmallInteger, alias: Bleed_Rate )
• Pol_Ag_Rate ( type: esriFieldTypeSmallInteger, alias: Pol_Ag_Rate )
• Drain_Rate ( type: esriFieldTypeSmallInteger, alias: Drain_Rate )
• Ride_Rate ( type: esriFieldTypeSmallInteger, alias: Ride_Rate )
• Traffic_Rate ( type: esriFieldTypeSmallInteger, alias: Traffic_Rate )
• CG_Rate ( type: esriFieldTypeString, alias: CG_Rate, length: 30 )
• SW_Rate ( type: esriFieldTypeString, alias: SW_Rate, length: 30 )
• ESRI_OID ( type: esriFieldTypeOID, alias: ESRI_OID, length: 8 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
